Rubber crushing machine

Previous Next


Type Technical parameter	XKP-400	XKP-450	XKP-560
( mm) Front roll diameter	400	450	560（510）
( mm) Rear roll diameter	400(Groove roller)	450(Groove roller)	510 ( 560 )(Groove roller)
( mm) Working length of rolls	600	650	800
( m/min) Front roll surface speed	17.32	23.2	25.56
Friction ratio	1:1.38	1:1.38	1:1.30
( mm) Max.nip	8	8	15
( kw) Motor power	45	55	75（90）
( mm) Overall dimension:Length×Width×Height	3950 x1800 x1780	4770 x1846 x 1835	5064 x 2284 x 1978
